Trina Solar Vertex S (R) 420W Triple-cut Black Frame (TSM-420-DE09R.08)

Manufacturers part number TSM-420-DE09R.08
Our reference 31-113532

Technical details

Watt 420 Module type Monofacial Framed Number of cells 144 (72)
Watt/m² 210,0 Module surface (m²) 1,998
Cell Triple-cut Cell Technology G12R (210x182mm)
Module efficiency 21,0% Temp. Coef PMAX -0,34%/K
Panel frame color Black
Dimensions 176,2 x 113,4 x 3,0 cm Weight 21,8kg
Cable length 1 100mm - MC4-EVO2 connectors
Junction box Split box - Mid
Product warranty 15 years
Performance warranty 84,8% after 25 years
Module packaging 36,0 per pallet - 936 per container
